| PERFORMANCE | |
| Max. prop shaft output | 11.0 kW / 15 HP |
| Full throttle operating range | 4000 ~ 4500 rpm |
| Idling speed | 900 ± 50 rpm |
| Fuel consumption | 7.3 L/h@5000 rpm |
| ENGINE | |
| Engine type | 2-Stroke, In-line 2 |
| Displacement | 246 cc |
| Bore × Stroke | 56.0 × 50.0 mm |
| Fuel induction system | 1 carburetor |
| Fuel tank | External, 24 L |
| Lubrication system | Pre-mixed fuel and oil (50 : 1) |
| Ignition system | CDI |
| Spark Plug | NGK B7HS-10 |
| Engine Start | Manual / Electric Start |
| Alternator | 6A, 80 W |
| Cooling system | Raw-water, thermostatically controlled |
| Propeller spec | 3-9 1/4'' x 9'' |
| BRACKET / DRIVE | |
| Steering | Tiller Handle |
| Steering Angle (maximum) | 45°from center, left and right |
| Trim Control System | Manual Tilt |
| Gear shift | F-N-R |
| Gear ratio | 2.08 (27/13) |
| Gear oil | 0.25 L |
| Engine transom height (Shaft length) | S: 440mm (17.3") / L: 570mm (22.4'') |
| Boat transom height | S: 380 mm / L: 510 mm |
| Dry weight | S: 36.5 kg / L: 38 kg |
| PACKAGE | |
| Gross weight | S: 46 kg / L: 48 kg |
| Package size | S: 112*64*37 cm / L: 125*64*37 cm |
