PERFORMANCE | |
Max. prop shaft output | 29.4 kW / 40 HP |
Full throttle operating range | 4500 ~ 5500 rpm |
Idling speed | 750 ± 50 rpm |
Fuel consumption | 20 L/h@5500 rpm |
ENGINE | |
Engine type | 2-Stroke, In-line 2 |
Displacement | 703 cc |
Bore × Stroke | 80.0 × 70.0 mm |
Fuel induction system | 1 carburetor |
Fuel tank | External, 24 L |
Lubrication system | Pre-mixed fuel and oil (50 : 1) |
Ignition system | CDI |
Spark Plug | NGK B7HS-10 |
Engine Start | Manual / Electric Start |
Alternator | 6A, 80 W |
Cooling system | Raw-water, thermostatically controlled |
Propeller spec | 3-11 1/8'' x 13'' |
BRACKET / DRIVE | |
Steering | Tiller Handle |
Steering Angle (maximum) | 45°from center, left and right |
Trim Control System | Manual Tilt |
Gear shift | F-N-R |
Gear ratio | 2.00 (26/13) |
Gear oil | 0.43 L |
Engine transom height (Shaft length) | L: 550mm (21.7'') |
Boat transom height | L: 500 mm |
Net weight | L: 79 kg |
PACKAGE | |
Gross weight | L: 100 kg |
Package size | L: 150.86.48 cm |
